Monitor performance metrics for your universe to ensure the universe configuration matches its performance requirements using the universe Metrics page.

The Metrics page displays graphs representing information on operations, latency, and other parameters accumulated over time. By examining specific metrics, you can diagnose and troubleshoot issues.

You access metrics by navigating to Universes > Universe-Name > Metrics, as shown in the following illustration:

Use the time menu to change the range. To zoom in to view granular data points, select a portion of the time range along the y-axis of any chart. This zooms all charts.

Click the refresh button to restore the default time range.

You can create custom PromQL queries and run them against any graph. To do this, from the Metrics page, click the Prometheus icon at the top right corner of any metrics graph to display the Prometheus window, then paste your query in the Prometheus query editor.

For example, to view the per-table p99 latency metrics, you can run the following PromQL query which uses the ql_read_latency_sum and ql_read_latency_count functions as follows:

label_replace(
   quantile_over_time(0.99, ((sum(rate(ql_read_latency_sum{node_prefix="<universe_name>", export_type="tserver_export", namespace_name!="system_platform"}[36s])) by (table_name))
   /
   (sum(rate(ql_read_latency_count{node_prefix="<universe_name>", export_type="tserver_export", namespace_name!="system_platform"}[36s])) by (table_name)))[30s:])
   , "quantile", "99", "table_name", "(.+)"
)

For more information, refer to Querying Prometheus in the Prometheus documentation.

Filter metrics

You can display metrics based on different criteria:

• If your universe has more than one region, cluster, zone, or node, the Metrics page allows you to view metrics for a specific region, cluster, zone, or node.

• You can view the overall node metrics which represent an aggregate across the selected nodes. Depending on the metric type, either an average across nodes or a sum of all node values is displayed.

• You can view metrics for up to five top or bottom outlier nodes. For example, to display graphs for the top three nodes with the highest CPU usage, you would select Outlier Nodes, then Top, and then 3 nodes. The graph also includes the average for all nodes.

  Note that Selected Node average in the graph means the average of all the nodes that you have selected. For example, if you have filtered by region, then the selected node average would be average of all nodes in the selected region.

• You can view metrics for up to seven top or bottom outlier tables, including both system and user tables. For example, to display graphs for two tables with the highest read latency, you would select Outlier Tables, then Top, and then 2 tables. The graph also includes the average for all tables.

  Note that the namespace name is appended with the table name and separated by a . (dot) operator.

• You can further restrict the outlier nodes or tables graphs to only display metrics for specific operations, events, statuses, and so on. For example, you can find out how many YSQL SELECT statements per second have been executed by the top-performing three nodes in the past six hours by selecting Last 6 hr > Outlier Nodes > Top > 3 nodes > YSQL Ops > Total YSQL Ops / Sec > Select.

Monitor your universe

You should do the following on a regular basis:

• Monitor remote bootstrap for node failures. You can access this metric via Tablet Server > Remote Bootstraps and Tablet Server > RPC Queue Size.
• Monitor the NTP server to ensure that it is running. You can access this information via your computer's operating system.
• Monitor clock skew so you can see when the clock is off by more than 500 milliseconds. You can access this metric via Node > Clock Skew.
• Monitor your disk usage. The default is 80% used, but you should consider this metric in the context of your environment. For example, the usage percentage can be higher on larger disks; some file systems issue an alert at 75% usage due to performance degradation. You can access this metric via your computer's operating system.
• Monitor YSQL and YCQL operations latency and tune it according to your application service level agreement. You can access this metric via YSQL Ops and Latency, YCQL Ops and Latency, YSQL Advanced, and YCQL Advanced.
• Monitor average read and write latency so you know when latency starts to degrade, at which point you should tune it according to averages. You can access this metric via Tablet Server > Average Latency.
• Monitor reactor delays to measure bottleneck of incoming requests. You can access this metric via Tablet Server > Reactor Delays.
• Monitor log statistics per node to measure churn in the log cache size to determine high rate of evictions. You can access this metric via Tablet Server > WAL Stats / Node.
• Monitor the tablet and master servers' RPC queue size so you can see all the subelements and know if there is a bottleneck that might cause performance degradation. You can access this metric via Tablet Server > RPC Queue Size and Master Server > RPC Queue Size.
• Monitor DocDB cache miss ratio so you can tune the cache when necessary. You can access this metric via DocDB > Cache Hit & Miss.

Universe metrics

The following tables describe metrics available via the YugabyteDB Anywhere UI.

YSQL ops and latency

Graph	Description	Alert Guidance	Example
Total YSQL Ops / Sec	The count of DELETE, INSERT, SELECT, and UPDATE statements through the YSQL API. This does not include index writes.	An alert should be issued if count drops significantly lower than your average count, as this might indicate an application connection failure. In addition, an alert should be issued if the count is much higher than your average count, as this could indicate a DDoS, security incident, and so on. It is recommended to coordinate this with the application team because there could be legitimate reasons for dips and spikes.
YSQL Op Latency (Avg)	Average time of DELETE, INSERT, SELECT, and UPDATE statements through the YSQL API.	An alert should be issued when the overall latency is close to or higher than your application SLA. Note that the overall latency metric is less helpful for troubleshooting specific queries. It is recommended that the application track query latency. Also note that there could be reasons your traffic experiences spikes in latency. For example, ad-hoc queries such as count(*) are executed.
Total YSQL Connections	Cumulative number of connections to YSQL backend for all nodes. This includes various background connections, such as checkpointer, as opposed to an active connections count that only includes the client backend connections.	By default, each YB-TServer node allows up to 300 connections. You should consider issuing an alert when the total connection count is close to 300*(number of YB-TServers).

YCQL ops and latency

Graph	Description	Alert Guidance	Example
Total YCQL Ops / Sec	The count of DELETE, INSERT, SELECT, and UPDATE transactions, as well as other statements through the YCQL API.	An alert should be issued if count drops significantly lower than your average count, as this could indicate an application connection failure.
YCQL Op Latency (Avg)	The average time of DELETE, INSERT, SELECT, and UPDATE transactions, as well as other statements through the YCQL API.	An alert should be issued when latency is close to or higher than your application SLA.
YCQL Op Latency (P99)	The average time of the top 99% of DELETE, INSERT, SELECT, and UPDATE transactions, as well as other statements through the YCQL API.	If this value is significantly higher than expected, then it might be a cause for concern and you might want to issue an alert. You should check whether or not there are consistent spikes in latency.

Resource

Resource metrics should be considered on a per-node basis.

Graph	Description	Alert Guidance	Example
CPU Usage	The percentage of CPU utilization on nodes being consumed by the tablet or master server Yugabyte processes, as well as other processes, if any. In general, CPU usage is a measure of all processes running on the server. The user CPU time is the amount of time the processor worked on all the processes. The system CPU time is the amount of time the processor worked on the operating system's functions connected to the processes.	If you have alerts enabled, you should check if you received any high CPU utilization alerts. These alerts could indicate a problem and may require debugging by Yugabyte Support.
Memory Usage (Buffered, Cached, Free)	The amount of RAM (in GB) available to the nodes in the cluster. The buffered memory is the size of in-memory block input/output buffers. The cached memory is the size of the page cache. Free memory is not in use.	An alert should not be issued on memory metrics directly. It is recommended to use another metric to troubleshoot the underlying problem causing any memory bottlenecks. The assumption is that the computer is dedicated to Yugabyte processes, therefore Yugabyte processes aggressively use the memory provided for caches and other operations.
Disk IOPS / Node	The number of disk input / output read and write operations per second averaged over each node.	Large spikes usually indicate large compactions. Rarely, in cases of a spiky workload, this could indicate block cache misses. Because random reads always hit disk, it is recommended to increase IOPS capacity for this type of workload. You should set an alert to a value much greater than your average or as a percentage of your available IOPS. This value is averaged across all nodes in a cluster. An alert should be issued per node to detect source of underlying issues.
Disk Bytes / Sec / Node	The number of bytes (scale: millions) being read or written to disk per second, averaged over each node.	If the maximum IOPS for the instance volume type has high utilization, you should ensure that the schema and query are optimized. In addition, consider increasing the instance volume IOPS capacity.
Network Packets / Sec / Node	The count of network packets received to the server (RX) and transmitted from the server (TX) per second, averaged over nodes.	Provides a view of the intensity of the network activity on the server. This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Network Bytes / Sec / Node	The size (in bytes; scale: millions) of network packets received (RX) and transmitted (TX) per second, averaged over nodes.	Provides a view of the intensity of the network activity on the server. This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Network Errors / Sec / Node	The number of errors related to network packets received (RX) and transmitted (TX) per second, averaged over nodes.	Generally, you should issue an alert for any error. If your environment produces a lot of errors, that could indicate an underlying infrastructure or operating system issue.
System Load Over Time	The measure of system load averaged over 1, 5, and 15 minutes.	Values greater than your configured number of cores indicates that processes are waiting for CPU time. It is recommended that you consider your averages when determining the alert threshold. In some cases, this can mean issuing an alert when the 5-minute load average is at 75-80% of available cores on the server. For some systems and workloads, you may want to set the threshold higher (for example, to 4 times the number of cores).
Clock Skew	For YugabyteDB to preserve data consistency, the clock drift and clock skew across different nodes are configured within bounds.	Clock skew is important for performance and data consistency. An OSS product can refuse to come up or can crash at a default value of 500 milliseconds, as it is considered better to be down than inconsistent. YugabyteDB Anywhere issues alerts at the same threshold, and it should be considered a top priority to resolve this alert.

YSQL advanced

Graph	Description	Alert Guidance	Example
Total YSQL Ops / sec	The number of various transaction control operations, such as BEGIN, COMMIT, ROLLBACK, as well as other operations through the YSQL API.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
YSQL Op Latency (Avg)	The average time taken by various transaction control operations, such as BEGIN, COMMIT, ROLLBACK, as well as other operations through the YSQL API.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.

YCQL advanced

Graph	Description	Alert Guidance	Example
YCQL Latency Breakdown	The average time spent by the CQL API parsing and executing operations.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
YBClient Ops Local vs Remote	The count of local and remote read and write requests. Local requests are executed on the same node that has received the request. Remote requests are re-routed internally to a different node for executing the operation.	If an application is using a Yugabyte driver that supports local query routing optimization and prepared statements, the expected value for this is close to 100% local for local reads and writes. If using the Cassandra driver or not using prepared statements, expect to see a relatively even split (for example, ~33% local and ~66% remote for a 3-node cluster).
YBClient Latency	Latency of local and remote read and write requests. Refer to the YBClient Ops Local vs Remote description regarding local and remote requests.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Reactor Delays	The number of microseconds the incoming CQL requests spend in the worker queue before the beginning of processing. Note that Reactor is a software implementation of a ring queue.	This value should be close to zero. If it is increasing or stays high, you should treat it as an indicator of a network issue or that the queues are full. If this is the case, you should investigate throughput and queue size and latency metrics for tuning guidance.
RPC Queue Size	The number of RPCs in the service queue.	The queue size is an indicator of incoming traffic and throughput. Typically, it either shows very low values, which means that YugabyteDB is processing requests at a healthy rate; or a flat line at the maximum-configured queue size, which means that YugabyteDB has filled the queues and cannot process fast enough.
Response Size (bytes)	The size of the RPC response.	The response size for RPCs should be relatively small. This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Transactions	The number of transactions.	This value depends on the application or activity. Because transactions can have batched statements, it's not possible to provide a specific guidance for this metric. You may consider this information while examining alerts on other metrics.
Inbound RPC Connections Alive	The count of current connections at the CQL API level.	If this spikes to a number much higher than your average, you should consider that there may be an active DDoS or a security incident.

Tablet server

Graph	Description	Alert Guidance	Example
Ops / Sec / Node	This is the key throughput measure. Read: the count of read operations at the tablet level. Write: the count of write operations at the tablet level.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Average Latency	Read: the average latency of read operations at the tablet level. Write: the average latency of write operations at the tablet level.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Reactor Delays	The number of microseconds the incoming RPC requests spend in the worker queue before the beginning of processing. Note that Reactor is a software implementation of a ring queue.	If this metric spikes or remains at a high level, it indicates a network issue or that the queues are full.
Threads Running	The current number of running threads.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Threads Started	The total number of threads started on this server.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Consensus Ops / Sec	Yugabyte implements the Raft consensus protocol, with minor modifications. Update: replicas implement an RPC method called UpdateConsensus which allows a leader to replicate a batch of log entries to the follower. Only a leader may call this RPC method, and a follower can only accept an UpdateConsensus call with a term equal to or higher than its currentTerm. Request: replicas also implement an RPC method called RequestConsensusVote, which is invoked by candidates to gather votes. MultiRaftUpdates: information pending.	A high number for the Request Consensus indicates that a lot of replicas are looking for a new election because they have not received a heartbeat from the leader. A high CPU or a network partition can cause this condition, and therefore it should result in issuing an alert.
Total Consensus Change Config	This metric is related to the Raft Consensus Process. ChangeConfig: the number of times a peer was added or removed from the consensus group. LeaderStepDown: the number of leader changes. LeaderElectionLost: the number of times a leader election has failed. RunLeaderElection: the count of leader elections due to a node failure or network partition.	You should issue an alert on LeaderElectionLost. An increase in ChangeConfig typically happens when YugabyteDB Anywhere needs to move data around. This may happen as a result of a planned server addition or decommission, or a server crash looping. A LeaderStepDown can indicate a normal change in leader, or it could be an indicator of a high CPU, blocked RPC queues, server restarts, and so on. You should issue an alert on LeaderStepDown as a proxy for other system issues.
Remote Bootstraps	The total count of remote bootstraps.	When a Raft peer fails, YugabyteDB executes an automatic remote bootstrap to create a new peer from the remaining ones. Bootstrapping can also be a result of planned user activity when adding or decommissioning nodes. It is recommended to issue an alert on a change in this count outside of planned activity.
Consensus RPC Latencies	RequestConsensus: latency of consensus request operations. UpdateConsensus: latency of consensus update operations. MultiRaftUpdates: information pending.	If the value is high, it is likely that the overall latency is high. This metric should be treated as a starting point in debugging the YB-Master and YB-TServer processes.
Change Config Latency	Latency of consensus change configuration processes.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Context Switches	Voluntary context switches are writer processes that take a lock. Involuntary context switches happen when a writer process has waited longer than a set threshold, which results in other waiting processes taking over.	A large number of involuntary context switches indicates a CPU-bound workload.
Spinlock Time / Server	Spinlock is a measurement of processes waiting for a server resource and using a CPU to check and wait repeatedly until the resource is available.	This value can become very high on large computers with many cores. The GFlag tserver_tcmalloc_max_total_thread_cache_bytes is by default 256 MB, and this is typically sufficient for 16-core computers with less than 32 GB of memory. For larger computers, it is recommended to increase this to 1 GB or 2 GB. You should monitor memory usage, as this requires more memory.
WAL Latency	This is related to WALs. Commit (Log Group Commit Latency): the number of microseconds spent on committing an entire group. Append (Log Append Latency): the number of microseconds spent on appending to the log segment file. Sync (Log Sync Latency): the number of microseconds spent on synchronizing the log segment file.	These metrics provide information on the amount to time spent writing to a disk. You should perform tuning accordingly.
WAL Bytes Written / Sec / Node	The number of bytes written to the WAL after the tablet start.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
WAL Bytes Read / Sec / Node	The number of bytes read from the WAL after the tablet start.	It is recommended to issue an alert on values higher than the normal range. An increase indicates that followers are falling behind and are constantly trying to catch up. In an xCluster replication topology, this can indicate replication latency.
WAL Ops / Sec / Node	This is related to WALs. Commit (Log Group Commit Count): the number of commits of an entire group, per second, per node. Append (Log Append Count): the number of appends to the log segment file, per second, per node. Sync (Log Sync Count): the number of syncs for the log segment file, per second, per node.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
TCMalloc Stats	In Use (Heap Memory Usage): the number of bytes used by the application. Typically, this does not match the memory use reported by the OS because it does not include TCMalloc overhead or memory fragmentation. Total (Reserved Heap Memory): the number of bytes of the system memory reserved by TCMalloc.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics. Also consider the following: Free Heap Memory: the number of bytes in free, mapped pages in a page heap. These bytes can be used to fulfill allocation requests. They always count towards virtual memory usage, and unless the underlying memory is swapped out by the OS, they also count towards physical memory usage. Unmapped Heap Memory: the number of bytes in free, unmapped pages in a page heap. These are bytes that have been released back to the OS, possibly by one of the MallocExtension Release calls. They can be used to fulfill allocation requests, but typically incur a page fault. They always count towards virtual memory usage, and depending on the OS, usually do not count towards physical memory usage. Thread Cache Memory Limit: a limit to the amount of memory that TCMalloc dedicates for small objects. In some cases, larger numbers trade off more memory use for improved efficiency. Thread Cache Memory Usage: a measure of some of the memory TCMalloc is using (for small objects).
WAL Stats / Node	WAL bytes read: the size (in bytes) of reads from the WAL after the tablet start. WAL cache size: the total per-tablet size of consensus entries kept in memory. The log cache attempts to keep all entries which have not yet been replicated to all followers in memory, but if the total size of those entries exceeds the configured limit in an individual tablet, the oldest is evicted.	If the log cache size is greater than zero, the followers are behind. You should issue an alert if the value spikes or remains above zero for an extended period of time.
WAL Cache Num Ops / Node	The number of times the log cache is accessed.	Outside of an xCluster replication deployment, a number greater than zero means some of the followers are behind.
Glog messages	The following log levels are available: Info: number of INFO-level log messages emitted by the application. Warning: number of WARNING-level log messages emitted by the application. Error: number of ERROR-level log messages emitted by the application.	Use a log aggregation tool for log analysis. You should review the ERROR-level log entries on a regular basis.
RPC Queue Size	The number of RPCs in service queues for tablet servers: CDC service Remote Bootstrap service Consensus service Admin service Generic service Backup service	The queue size is an indicator of the incoming traffic. If the backends get overloaded, requests pile up in the queues. When the queue is full, the system responds with backpressure errors. Also consider the following Prometheus metrics: rpcs_timed_out_in_queue - the number of RPCs whose timeout elapsed while waiting in the service queue, which resulted in these RPCs not having been processed. This number does not include calls that were expired before an attempt to execute them has been made. rpcs_timed_out_early_in_queue - the number of RPCs whose timeout elapsed while waiting in the service queue, which resulted in these RPCs not having been processed. The timeouts for these calls were detected before the calls attempted to execute. rpcs_queue_overflow - the number of RPCs dropped because the service queue was full.
CPU Util Secs / Sec	The tablet server CPU utilization.	The tablet server should not use the full allocation of CPUs. For example, on a 4-core computer, three cores are used by the tablet server, but if the usage is usually close to three, you should increase the number of available CPUs.
Inbound RPC Connections Alive	The count of active connections to YB-TServers.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.

Master server

Graph	Description	Alert Guidance	Example
Overall RPCs / sec	The number of created RPC inbound calls to the master servers.	The limit is 1000 TPS on the master, but under normal circumstances this number should be much lower than the limit. It is recommended to issue an alert at a range under the limit, yet higher than your average.
Average Latency	The average latency of various RPC services, provided by Master server	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
GetTabletLocations / sec	The number of times the locations of the replicas for a given tablet were fetched from the master servers.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Master TSService Reads / sec	The measure of YSQL reads of the PostgreSQL system tables.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Master TSService Reads Latency	The average latency of YSQL reads of the PostgreSQL system tables.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Master TSService Writes / sec	The measure of YSQL writes to the PostgreSQL system tables (during DDL).	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Master TSService Writes Latency	The average latency of YSQL writes to the PostgreSQL system tables (during DDL).	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
TS Heartbeats / sec	The count of heartbeats received by the master server leader from the tablet servers. This establishes liveness and reports back any status changes.	This measure can be used to determine which master is the leader, as only the leader gets active heartbeats.
RPC Queue Size	The number of RPCs in a service queue for master servers.	The queue size is an indicator of the incoming traffic. This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
UpdateConsensus / sec	The number of consensus update operations.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
UpdateConsensus Latency	Latency of consensus update operations.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
MultiRaftUpdateConsensus / sec	The number of multiple Raft group consensus update operations.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
MultiRaftUpdateConsensus Latency	Latency of multiple Raft group consensus update operations.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Create / Delete Table RPCs	The count of administrative operations CreateTable and DeleteTable.	A deletion can fail when other operations, such as bootstrap, are running. This uses a configured retry timeout.
CPU Util Secs / Sec (Master Server)	The master server CPU utilization.	The master server should not use a full CPU.
Inbound RPC Connections Alive	The count of active connections to master servers.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.

Master server advanced

Graph	Description	Alert Guidance	Example
Threads Running	The current number of running threads.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
WAL Latency	This is related to WALs. Commit (Log Group Commit Latency): the number of microseconds spent on committing an entire group. Append (Log Append Latency): the number of microseconds spent on appending to the log segment file. Sync (Log Sync Latency): the number of microseconds spent on synchronizing the log segment file.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
WAL Bytes Written / Sec / Node	The number of bytes written to the WAL after the tablet start.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
WAL Bytes Read / Sec / Node	The number of bytes read from the WAL after the tablet start.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
TCMalloc Stats	In Use (Heap Memory Usage): the number of bytes used by the application. Typically, this does not match the memory use reported by the OS because it does not include TCMalloc overhead or memory fragmentation. Total (Reserved Heap Memory): the number of bytes of the system memory reserved by TCMalloc.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Glog Messages	The following log levels are available: Info: the number of INFO-level log messages emitted by the application. Warning: the number of WARNING-level log messages emitted by the application. Error: the number of ERROR-level log messages emitted by the application.	It is recommended to use a log aggregation tool for log analysis. You should review the ERROR-level log entries on a regular basis.
LSM-DB Seek / Next Num Ops	The number of calls to seek / next.	Alerting is not required.
LSM-DB Seeks / sec	The number of calls to seek per second.	Alerting is not required.
SSTable size	The size (in bytes) of all SST files.	Alerting is not required.
Cache Hit & Miss	Hit: the total number of block cache hits (cache index + cache filter + cache data). Miss: the total number of block cache misses (cache index + cache filter + cache data).	If the number of misses is significant, it is recommended to issue an alert.
Block cache usage	A block requires multiple touches before it is added to the multi-touch (hot) portion of the cache. Multi Touch: the size (in bytes) of the cache usage by blocks having multiple touches. Single Touch: the size (in bytes) of the cache usage by blocks having only a single touch.	Alerting is not required.
LSM-DB Blooms usefulness	Blooms checked: the number of times the bloom filter has been checked. Blooms useful: the number of times the bloom filter has avoided file reads (avoiding IOPS).	Alerting is not required.
Flush write	The number of bytes written during the flush process.	Alerting is not required.
Compaction	The number of bytes being read and written to do compaction. If not a lot of data is being deleted, these levels are similar. In some cases, you might see a large delete indicated by large reads but low writes afterwards (because a large percentage of data was removed in compaction).	Alerting is not required.
Compaction time	Time (in milliseconds) for the compaction processes to complete.	Alerting is not required.
Compaction num files	The average number of files in any single compaction.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.

DocDB

DocDB uses a highly customized version of RocksDB, a log-structured merge tree (LSM)-based key-value store. The majority of the following metrics are used internally by engineers when troubleshooting a deployment, and, therefore, should not be subject to alerting.

Graph	Description	Alert Guidance	Example
LSM-DB Seek / Next Num Ops	The number of calls to seek / next.	Alerting is not required.
LSM-DB Seeks / Sec / Node	The number of calls to seek per second per node.	Alerting is not required.
SSTable size / Node	The size (in bytes) of all SST files.	Alerting is not required.
Average SSTables / Node	The average number of SST files across nodes.	Alerting is not required.
LSM-DB Get Latencies	Latency in time to retrieve data matching a value.	Alerting is not required.
LSM-DB Write Latencies	Latency in time to write data.	Alerting is not required.
LSM-DB Seek Latencies	Latency in time to retrieve data in a range query.	Alerting is not required.
LSM-DB Mutex Wait Latencies	The wait time for the DB mutex. This mutex is held for meta operations, such as checking data structures before and after compactions or flushes.	Alerting is not required.
Cache Hit & Miss	Hit: the total number of block cache hits (cache index + cache filter + cache data). Miss: the total number of block cache misses (cache index + cache filter + cache data).	If the number of misses is significant, it is recommended to issue an alert.
Block cache usage	A block requires multiple touches before it is added to the multi-touch (hot) portion of the cache. Multi Touch: the size (in bytes) of the cache usage by blocks having multiple touches. Single Touch: the size (in bytes) of the cache usage by blocks having only a single touch.	Alerting is not required.
LSM-DB Blooms usefulness	Blooms checked: the number of times the bloom filter has been checked. Blooms useful: the number of times the bloom filter has avoided file reads (avoiding IOPS).	Bloom filters are hash tables used to determine if a given SSTable has the data for a query looking for a particular value. Bloom filters are not helpful for range queries, and therefore alerting is not required.
Stalls	Time the writer has to wait for compactions or flushes to finish.	Alerting is not required
Rejections	The number of RPC requests rejected due to the number of majority SST files.	Rejections can happen due to hitting the soft limit on SST files, hitting more than the soft memory limit (set to 85% of the hard limit), and so on. Alerting is not required.
Flush write	The number of bytes written during the flush process.	Alerting is not required.
Compaction	The number of bytes being read and written to do compaction. If not a lot of data is being deleted, these levels are similar. In some cases, you might see a large delete indicated by large reads but low writes afterwards (because a large percentage of data was removed in compaction).	Alerting is not required.
Compaction time	Time for the compaction processes to complete.	Alerting is not required.
Compaction num files	The average number of files in any single compaction.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.
Transaction	Expired Transactions: the number of expired distributed transactions. Transaction Conflicts: the number of conflicts detected among uncommitted distributed transactions. This is related to the process that resolves conflicts for write transactions. This process reads all intents that could conflict and tries to abort transactions with a lower priority. If a write transaction conflicts with a higher-priority transaction, then an error is returned and this metric is iterated.	Alerting is not required.
Transaction pool cache hits	Percentage of transaction pool requests fulfilled by the transaction pool cache.	This metric is informational and should not be subject to alerting. You may consider this information while examining alerts on other metrics.

Command-line access to metrics

YugabyteDB Anywhere allows you to access all metrics via the command-line interface (CLI), including those not available from the Metrics page.

You can view YB-TServer and YB-Master server metrics in Prometheus and JSON formats in the browser or via the CLI using curl commands.

The following is the Prometheus command for the YB-TServer:

curl <node_IP>:9000/prometheus-metrics

Expect an output similar to the following:

The following is the Prometheus command for the YB-Master:

curl <node_IP>:7000/prometheus-metrics

The following is the JSON command for the YB-TServer:

curl <node_IP>:9000/metrics

Expect an output similar to the following:

The following is the JSON command for the YB-Master:

curl <node_IP>:7000/metrics

You can obtain additional information if you request the schema in the metrics URL, as follows:

curl <node_IP>:9000/metrics?include_schema=true

curl <node_IP>:7000/metrics?include_schema=true

The output would be similar to the following:

[
    {
        "type": "tablet",
        "id": "aaec98a6a44a418999f325d637f9e8cf",
        "attributes": {
            "partition": "hash_split: [0xBFFA, 0xDFF9)",
            "namespace_name": "mykeyspace",
            "table_name": "foo",
            "table_id": "63e3fee5f5f441eeb5a5071ebd64c232"
        },
        "metrics": [
            {
                "name": "mem_tracker_log_cache",
                "label": "Memory consumed by log_cache-aaec98a6a44a418999f325d637f9e8cf->log_cache->server->root",
                "type": "gauge",
                "unit": "bytes",
                "description": "Memory consumed by log_cache-aaec98a6a44a418999f325d637f9e8cf->log_cache->server->root",
                "level": "info",
                "value": 0
            },
            {
                "name": "mem_tracker_RegularDB_MemTable",
                "label": "Memory consumed by MemTable->RegularDB->tablet-aaec98a6a44a418999f325d637f9e8cf->Tablets->server->root",
                "type": "gauge",
                "unit": "bytes",
                "description": "Memory consumed by MemTable->RegularDB->tablet-aaec98a6a44a418999f325d637f9e8cf->Tablets->server->root",
                "level": "info",
                "value": 2048
            },
...

You can also federate metrics from YugabyteDB Anywhere and configure alerting rules to trigger alerts in Prometheus. For details, see the following sections of Alerts and Notifications in YugabyteDB Anywhere:

• Scrape metrics from YugabyteDB Anywhere
• Configurable alerting rules
